nº1030



Experimental MW reflex regenerative receiver with 1 bipolar transistor, 10mts wire antenna+PE; loudspeaker volume, supply 3V

nº1029



Squegging joules thief with piezoelectric speaker

nº1028



Mains voltage hot wire detector with piezoelectric speaker.

nº1027



Experimental reflex regenerative LW receiver (150kHz-250kHz), supply 3V

nº1026



Minimalist MW TRF radio receiver: 10mts wire antenna + PE; supply +5V_USB



nº1025



Led voltmeter(VCO); range 0-10V; 5 bipolar transistors; Yellow led flashes an amount of times equal to the input voltage; supply 12V

nº1024



Minimalist "heads or tails" game, supply +5V_USB

nº1023



nº1022



Experimental MW reflex receiver with 3 BC transistors, supply 2xR03

nº1021



Simple audio temperature probe with 2 transistors, supply 1,5V

nº1020



Simple astable multivibrator with 3 independent controls: led brightness, frequency and duty-cycle, supply +5V_USB

nº1019



Heads or tails game with accelerating leds, supply +5V_USB

nº1018

20 green leds bidirectional bar, supply +5V_USB



nº1017



Minimalist phase-shift oscillator drives piezoelectric loudspeaker to make a simple buzzer, supply +5V_USB

nº1016



Minimalist phase-shift oscillator drives green led inserted in the feedback network, supply +5V_USB

nº1015



Squegging transistor negistor with blue led, 5 components, supply 12V

nº1014



Harvesting solar energy by 10 superbright 5mm yellow leds to run a low consumption led chaser. Although a small photovoltaic panel salvaged from an electronic calculator is being used in this demonstration, the leds themselves alone  will run the sequencer when the protoboard is exposed to direct sunlight. Superbright leds are required.

nº1013



Experimental reflex receiver for MW band with 2 transistors and 3V supply voltage is tuned by AM varicap diode BB212 having noiseless voltage supply generated by 4 photovoltaic couplers.

nº1012



Accurate USB power meter with 5 transistors. Maximum power about 400mW.

nº1011



Accurate analog computer with 3 bipolar transistors multiplies two DC voltages ranging Vx from 1V up to 5V and Vy from 0.1V up to 0.9V, supply +5V_USB

nº1010



Single capacitor symmetrical astable multivibrator, supply +5V_USB

nº1009



Minimalist transistor phase-shift oscillator with 7 components. Higher supply voltages allow very low frequency with low capacitor values, supply 24V

nº1008



The multimeter dancing needle, supply 3V

nº1007



Led chaser with 2 active blue leds changing the stop position, supply +5V_USB

nº1006



nº1005



Experimental regenerative radio receiver for MW with one transistor; loudspeaker volume, low impedance(32 Ohm) 40mm loudspeaker; random wire antenna with 5mts; mains PE connection; tuning broadcast radio station at 630kHz disted about 30km from 50kW transmitter; groundwave propagation; supply 2xR03.

nº1004



Simple DC considerations about avalanche diode emulator.

nº1003



Dual led flasher, supply 230Vac 50Hz

nº1002



Mains supplied bicolor led flasher; Flash rate and led color are controlled by a single potmeter.
